THE ULTIMATE manufaktur
Starting from
From £670 per month
2.3M (7ft 6")
| A | Load Length | 4125mm |
| B | Load Height | 2300mm |
| C | Load Width | 2100mm |
| D | Height Through Rear Doors | 2105mm |
| E | Width through Rear Doors | 1935mm |
| F | Between Wheel Arches | 1495mm |
| G | Bulk Head to Wheel Arches | 2500mm |
| H | Wheel Arch to Rear Frame | 710mm |
| I | Wheel Arch Height | 300mm |
| J | Wheel Arch Length | 865mm |
| K | Wheel Arch Width | 310mm |
| L | Total Length | 6690mm |
| M | Total Height | 2865mm |
| N | Total Width Excluding Mirrors | 2140mm |
| O | Total Width Including Mirrors | 2490mm |
| P | Loading Height [STD SUSP] | 550mm |
| Q | Ground Clearance | 320mm |
| R | Wheel Base | 4500mm |
| S | Rear Overhang | 765mm |
| Gross Vehicle Weight | 3500kg |
| Payload | up to 1500kgs |
| Cubic Capacity | up to 20m3 |
| Chassis Type | KoMAX |
| Suspension | Premium Independent Torsion Bar |
Starting from
From £691 per month
2.5M (8ft 2")
| A | Load Length | 4125mm |
| B | Load Height | 2540mm |
| C | Load Width | 2300mm |
| D | Height Through Rear Doors | 2325mm |
| E | Width through Rear Doors | 2135mm |
| F | Between Wheel Arches | 1695mm |
| G | Bulk Head to Wheel Arches | 2500mm |
| H | Wheel Arch to Rear Frame | 710mm |
| I | Wheel Arch Height | 300mm |
| J | Wheel Arch Length | 865mm |
| K | Wheel Arch Width | 310mm |
| L | Total Length | 6690mm |
| M | Total Height | 3175mm |
| N | Total Width Excluding Mirrors | 2340mm |
| O | Total Width Including Mirrors | 2690mm |
| P | Loading Height [STD SUSP] | 550mm |
| Q | Ground Clearance | 320mm |
| R | Wheel Base | 4500mm |
| S | Rear Overhang | 765mm |
| Gross Vehicle Weight | 3500kg |
| Payload | up to 1390kgs |
| Cubic Capacity | up to 24m3 |
| Chassis Type | KoMAX |
| Suspension | Premium Independent Torsion Bar |
We understand that every business is unique and different just as you are, that’s why Maxi Mover Have developed an unrivalled range of low floor luton vans to suit all of your needs and buying Decisions, designed and built for the only business that matters... yours.
